Catalog Number - 49681-05-005

The 49681-05-005 ARE‑Applied Research Inline Filter is an all‑PEEK inline filtration solution supplied in a multi‑unit pack, designed for HPLC systems operating under standard pressure conditions.

Using replaceable PEEK‑encased stainless steel (0.5 µm) filter elements, this system helps reduce particulate contamination, minimize system noise, and prevent column clogging, improving analytical consistency and column lifespan. The filter also functions as an inline union with filtration, adding flexibility to system setup.

Each unit features a reusable holder and is designed for quick installation and easy filter replacement, making it well suited for routine laboratory use.

Key Features

All‑PEEK Housing

• Chemically inert, metal‑free construction

• Compatible with a wide range of HPLC solvents

Replaceable 0.5 µm SS Filter Elements

• PEEK‑encased stainless steel filters for fine particulate removal

• Supports consistent performance and extended column life

✅ Replacement option available:

• Replacement PEEK‑Encased Stainless Steel Inline Filters, 0.5 µm, 6.25 mm OD × 1/16 inch Thick – Pack of 10

Designed for Standard HPLC Conditions

• Suitable for:

  • Typical analytical flow rates up to ~5 mL/min

  • Pressures up to ~4,500 psi

⚠️ Not recommended for UHPLC pressure ranges

Column & Instrument Protection

• Helps reduce:

  • Clogging and blockages

  • Background noise and variability

• Extends column and system lifespan

Reusable Filter Holder

• Designed for long‑term use

• Economical and practical for routine workflows

Easy Installation & Maintenance

• Install after the pump and before the injector

• Standard HPLC fittings

• Hand‑tight or wrench installation

• Quick replacement when system pressure increases

Flexible Filter Compatibility

• Accepts PEEK‑encased filters (6.25 mm OD × 1/16 inch thick)

• Supports use of different porosities as needed

✅ Also available:

• Economical Pack of 10 PEEK Inline Filter Holders with 0.5 µm Stainless Steel Filters

Specifications

• Type: Inline HPLC Filter with Replaceable Elements

• Housing Material: All‑PEEK

• Filter Material: PEEK‑encased stainless steel

• Pore Size: 0.5 µm

• Filter Dimensions: 6.25 mm OD × 1/16 inch thick

• Connection Type: Female

• Pressure Range: Up to ~4,500 psi

• Flow Rate Range: Up to ~5 mL/min

• Compatibility: Standard HPLC systems (not UHPLC)

• Brand: ARE‑Applied Research

Typical Applications

HPLC systems, mobile phase filtration, column protection, pharmaceutical and environmental analysis, and applications requiring fine particulate removal and improved system reliability
